Travel |
|||
|
Category |
Item |
Unit |
Parameter |
|
Chassis |
Model |
|
FM440 |
|
Manufacturer |
|
VOLVO |
|
|
Max. speed |
km/h |
90 |
|
|
Max. gradeability |
|
38% |
|
|
Min. turning diameter |
m |
27.4 |
|
|
Brake distance |
m |
≤10 |
|
|
Wheelbase |
mm |
1995+5205+1370+1450 |
|
|
Tread (front/rear) |
mm |
2028/1872 |
|
|
Approach angle/departure angle |
。 |
18/12 |
|
|
Min. clearance |
mm |
270 |
|
|
Tyre specification |
|
12.00R20 |
|
|
Engine |
Model |
|
D13 |
|
Output power |
kw/(r/min) |
324/1400~1800 |
|
|
Max. torque |
N.m/(r/min) |
2200/1050~1400 |
|
|
Displacement |
l |
12.8 |
|
|
Emission Standard |
|
Nation III GBⅢ |
|
|
Others |
Dimension (Length×Width×Height) |
mm |
14665×2500×3990 |
|
Total vehicle weight |
kg |
47000 |
|
|
Fuel tank capacity |
l |
410 |
|
|
Fuel consumption per 100km |
l/100km |
50 |
|
|
Pumping operation |
|||
|
Pumping system |
Theoretical output(high pressure/low pressure) |
m3/h |
90/138 |
|
Concrete pumping pressure(high pressure/low pressure) |
Mpa |
13/8.7 |
|
|
Theoretical pumping times(high pressure/low pressure) |
次/min |
18/27 |
|
|
Max. diameter of pumping concrete aggregate |
|
40 |
|
|
Feeding height |
|
1450 |
|
|
Placing boom |
Pumping slump range |
|
12-23 |
|
Reach height |
|
51.5 |
|
|
Reach depth |
|
40 |
|
|
Slewing radius |
|
47.5 |
|
|
Slewing angle |
|
364 |
|
|
1st boom stretch angle |
|
96 |
|
|
2nd boom stretch angle |
|
180 |
|
|
3rd boom stretch angle |
|
180 |
|
|
4th boom stretch angle |
|
180 |
|
|
5th boom stretch angle |
|
260 |
|
|
Outrigger spanOverall outrigger span |
11020±50 |
||
|
Front outrigger transverse span |
10730±50 |
||
|
Rear outrigger transverse span |
10430±50 |
||
|
Others |
Dosing type |
|
S valve |
|
Lubricating method |
|
Automatic lubrication |
|
|
Controlling method |
|
Manual/remote control |
|
|
Water tank capacity |
|
650 |
|
|
Max. pressure of water pump |
|
2 |
|
