SQ16SK4Q Truck-Mounted Crane
Parameter
| Unit | ||
|---|---|---|
|
Max Lifting Capacity |
16000 |
kg |
|
Max Lifting Moment |
40 |
T.M |
|
Recommend Power |
45 |
kw |
|
Max Oil Flow of Hydraulic System |
80 |
L/min |
|
Max Pressure of Hydraulic System |
28 |
MPa |
|
Oil Tank Capacity |
260 |
L |
|
Rotation Angle |
All Rotation |
|
|
Crane Weight |
6020 |
kg |
|
Installation Space |
1400 |
mm |
|
Choice of Chassis |
BJ1317VNPJJ-S5北汽福田；NXG1310D3ZEX徐工；DFL1311A3东风 ； |
|
|
Working radius(m) |
2.7 |
5.6 |
8.5 |
11.5 |
14.5 |
18.5 |
|
Lifting capacity(kg) |
16000 |
7000 |
4200 |
3200 |
2200 | 1000 |
