SQ4ZK2 Truck-Mounted Crane
Parameter
|
|
||
|---|---|---|
|
Max Lifting Moment |
8.4 |
t.m |
|
Max Lifting Capacity |
4000 |
kg |
|
Recommend Power Needed At Recommend Oil Flow |
14 |
kw |
|
Max Oil Flow of Hydraulic System |
25 |
L/min |
|
Rated Pressure Of Hydraulic System |
26 |
MPa |
|
Oil Tank Capacity |
60 |
L |
|
Rotation Angle |
370 |
。 |
|
Crane Weight |
1200 |
kg |
|
Installation Space |
850 |
mm |
|
Choice of Chassis |
EQ1092FJ1东风；EQ1092FJ东风；DFL1120B D530东风；EQ1081GJ12D5东风；HFC1132KR1K3江淮；LZ1120LAPT东风柳汽；HFC1083K103R1D江淮；EQ1092F3GJ1东风；EQ5121GFJ东风； |
|
| Working radius (m) | 2.1 | 4.15 | 5.8 | 7.3 |
| Lifting capacity (kg) | 4000 | 1840 | 1260 | 920 |
