Item

Unit

Model

HBTS90X14

Displacement

Low pressure

m³/h

90

High pressure

m³/h

50

transmission pressure

Low pressure

MPa

8

High pressure

MPa

14

S valve change number

Low pressure

cycle/min.

20

High pressure

cycle/min.

12

Transport cylinder inner diameter × stroke

mm

φ230×1800

Main cylinder inner diameter × stroke

mm

φ150×1800

Valve form

SValve

Hopper volume

m³

0.65

Products outlet
diameter

mm

φ180

Maximum allow aggregate diameter

mm

40

Engine

Model

6CTAA-C250、6CTAA8.3-C260

Engine power

kW/r/min

198/2000、196/2000

Hydraulic system

Main system form

Open style

Main pump

190

oil tank capacity

ml/r

600

Dimension

L

L

6960

W

mm

2100

H

mm

2770

Operating weight

mm

 7530

Switch form of high and low pressure

AUTO

Water tank capacity

　L

100

Oil tank capacity

  L

210
