XCMG Horizontal Drectional Drill XZ500
|
Model |
|
XZ500 |
|
Engine |
|
CUMMINS |
|
Rated power |
kW |
194 |
|
Max.pullback/thrusting |
kN |
500/500 |
|
Spindle torque (max) |
N.m |
18000 |
|
Spindle speed |
r/min |
0-108 |
|
Backreaming diameter |
mm |
Ø900 |
|
Tubing length(single) |
m |
4.5 |
|
Tubing diameter |
mm |
Ø89 |
|
Entry angle |
° |
10-20 |
|
Mud flow rate (max) |
L/min |
600 |
|
Mud pressure (max) |
bar |
100 |
|
Overall weight |
kg |
18000 |
|
Dimension(LxWxH) |
mm |
9280×2755×3000 |
