GR260 Motor Grader

                                                                                         GR260 Motor Grader

GR260
Basic specification
Engine model
6CTA8.3—C260
Rated power/speed
194kW/2200rpm
Dimension(LxWxH)
10280×3100×3550mm
Operating weight(Standard)
24000kg
Performance specification
Travelling speed ,forward
5、8、11、19、23、38 km/h
Travelling speed ,reverse
5、11、23 km/h
Tractive force(f=0.8)
132KN
Max. gradeability
36%
Tire inflation pressure
350 MPa
Working hydraulic pressure
18 MPa
Transmission pressure
1.3~1.8MPa
Operating specification
Max. steering angle of front wheels
Left / Right 50°
Max. lean angle of front wheels
Left / Right 17°
Max. oscillation angle of front axle
Up / down 15°
Max. oscillation angle of balance box
Before / after 15
Frame articulation angle
Left / Right 27°
Min. turning radius using articulation
8.3m
Biade
Maximum lift above ground
450mm
Maximum depth of cutting
500mm
Maximum blade position angle
90°
Blade cutting angle
28°—70°
Circle reversing rotation
360°
Moldboard width X height
4572×787mm



              All technical parameters are subject to change without prior notice because of technical improvements.
