XR160 Rotary Drilling Rig

The XR series of rotary drilling rig is produced by Xugong Group through years of research and development,

with wide reference to advanced overseas technologies, depending on the powerful strength of construction

machinery manufacturing. The product has good quality and reliability, and it is applicable to the ground

conditions in most places in China.


XR series of rotary drilling rig
Technical Features:
•Telescopic crawler chassis, box type frame, suitable rigidity, good stability.
•Automatic slewing positioning function
•Load sensing hydraulic system.
•Color LCD, automatic measuring of the boring depth and vertical rake, and automatic alarming system in case of failures.
•GPS global positioning system, remote data analysis, remote real time monitoring, and remote troubleshooting.



Main Technical Data of XR Series Multi-functional Combined Rotary Drilling Rig



model





XR160

Engine

Model



CUMMINS 6CTA8.3-C240

Rated Power

KW/rpm

177

Rotary Dvive

Max. output torque

kN·m

160

Rotary speed

r/min

826

Max. Drilling Diameter

With casing

mm

Ф1200

Without casing

mm

Ф1600

Max. Drilling Depth

m

54,42

Pull-Down Cylinder

Max. pull-down piston push

KN

160

Max. pull-down piston pull

KN

180

Max. pull-down piston stroke

m

5.0

Main Winch

Max. pulling force

KN

150

Max. pulling speed

m/min

80

Auxiliary Winch

Max. pulling force

KN

75

Max. pulling speed

m/min

≥70

Mast Rake

Side/forwards/backwards



±5°/5°/15°

Undercarrige

Max. traveling speed

KM/h

2.0

Max. grade ability

%

40

Min. Clearance

mm

460

Track shoe width

mm

600

Distance between tracks

mm

23403340

Hydraulic Systerm

Working pressue

Mpa

30

Overall Drilling Weight

t

56

Dimension

Working condition

mm

8105×3940×18230

Transportation condition

mm

13645×2940×3380
