QY35G Truck Crane


KaiFan Brand 35T (WUYUE) Crane Technical Parameters

KFM5353JQZ35G – QY35G



Working Condition

1Altitude: 0-4500m

2Temperature: -25℃--+45℃

3Allowed working condition: solid, stable land, the vehicle should be horizontal

4Wind force: ≤6 degree



Working Range

“KAI FAN” Brand KFM5353JQZ35GQY35GCrane is fully hydraulic telescopic crane, the maximum rated lifting capacity is 35t. It can be applied in various conditions for lifting and installation work, such as industrial and mining establishments, building site, station, sea port, warehouse and so on.



Main Parameters

Items

Unit

Value

Working Performance  Parameters

Max. Rated lifting weight

kg

35000

Max. Lifting force of the basic boom

kn.m

1225

Max. Height of the basic boom

m

11.2

Max. Lifting force of the longest main boom

kn.m

638

Max. Height of the main boom

m

33

Max. Height of the vice boom

m

48

Max. Speed of the single rope

m/min

110

Working Speed

Turning speed

r/min

0-2.4

Lifting time of the lift boom

s

70

Extension time of the lift boom

s

50

Traveling Parameters

Max. Traveling speed

km/h

70

The whole weight

kg

35040

Max. Grade ability

%

26

Min. Turning radius

m

12

Min. Ground clearance

m

0.23

Approaching angle

°

17

Departure angle

°

11

Dimension Parameters

External dimensionlength×width×height

mm

13312×2494×3500

Vertical span of outrigger

m

5.4

Horizontal span of outrigger

m

6.0

Length of main boom

m

10.5~33

Elevation of boom

°

-2~80

Length of vice boom

m

8.5~14.5

Chassis

Model

TAZ5363J

Engine model

WP10-290

Rated power/speed

kw/r/min

213/2200

Max. Torque/rotate speed

n.m/r/min

1160/1300-1600



Standard Equipments

1.         WUYUE TAZ5363J

2.         Main boom assembly

3.         Vice boom assembly

4.       Hanging hook assembly

5.        Windlass assembly

6.        Slewing system

7.        Electric system

8.        Hydraulic system

9.        Outrigger

10.      Superstructure control system

11.       Chassis control system

12.       Tool box



Vehicle Information

1.       Manual Instruction  (one set)

2.       Operation manual of chassis  (one set)

3.       Guarantee of chassis  (one set)

4.       Certification of quality of the vehicle  (one set)

5.        Maintenance Manual (Operation instruction) (one set)

6.        Operating safety certification  (one set)
