FR80H Excavator


FR80H Excavator

Product Features of FR80H

1. Japan Yanmar engine

2. Hydraulic control valves from KYB/REXROTH system, main pump from KYB/REXROTH/CASAPPA, high efficient and reliable;

3. Design and manufacture of structural components reach to world-class level;

4. Fashionable and safe driving cab

Parameter Items

Parameter Value

1.The main parameters



Operating weight (kg)

8300

Standard bucket capacity (m3)

0.32

Transport dimensions (L × W × H) mm

6100*2275*2485

Bucket digging force (kN)

61

Stick digging force (kN)

44

Maximum Traction force (kN)

83

2. Walking device



High and low speed Km / h

5.2/2.6

Grade ability (°)

30

Ground pressure(Kpa)

37

Rotating device



Rotating Speed (rpm)

11.5

4.Engine



Model

ISUZU AA-4JG1TPC

Type

Four-cylinder, direct injection, naturally aspirated, water-cooled

Rated power / speed (kW / rpm)

54.3/2150

Bore × strokemm

95.4×107

Displacement L

3.059

Fuel consumptiong / kW • h

257

Fuel tank capacity

110

5.Hydraulic system



Main pump pressure Mpa

24.5

Main pump flow L / min

160

6.Operation range



Maximum digging heightmm

7150

Maximum unloading heightmm

5030

Maximum digging depthmm

4050

Maximum digging radiusmm

6190

Bulldozing Blade size L x W mm

2256*406
