QY70K Truck Crane

QY70K Truck Crane



Parameter



Classificatory

Item

Unit

Parameter

Outline dimension

Overall length

mm

13500

Overall width

mm

2800

Overall height

mm

3510

Wheel base

Axle 1, Axle 2

mm

1520

Axle 2, Axle 3

mm

3965

Axle 3, Axle 4

mm

1350

Mass

Total mass in travel state

kg

41000

Axle load

Axle 1, Axle 2

kg

15000

Axle 3, Axle 4

kg

26000

Travel performance

Travel speed

Max. travel speed

km/h

75

Turning  diameter

Min. turning diameter

m

24

Min. turning diameter at boom tip

m

29.0

Min. ground clearance

mm

270

Approach angle

(°)

16.5

Departure angle

(°)

11.3

Braking distance (at speed of 30km/h)

m

≤10

Max. grade-ability

40

Fuel consumption for 100km

L

42

Power

Engine rated output

kW/(r/min.)

266/2208

EnEngine rated torque

N.m/(r/min.)

1460/1400

Engine rated speed

rpm.

2200



The specification is subject to change without notice.
