GR100 Motor Grader

                                                                                                            GR100 Motor Grader

Basic specification
Engine model 4BT3.9
Rated power/speed 75/2400kw/rpm
Dimension(LxWxH) 6880×2375×3150mm
Operating weight(Standard) 7000kg
Performance specification
Travelling speed ,forward 5、10、20、39km/h
Travelling speed ,reverse 8、25km/h
Tractive force(f=0.75) 41.6KN
Max. gradeability 20%
Tire inflation pressure 350KPa
Working hydraulic pressure 16MPa
Transmission pressure 1.3~1.8MPa
Operating specification
Max. steering angle of front wheels ±50°
Max. lean angle of front wheels 17°
Max. oscillation angle of front axle ±15°
Max. oscillation angle of balance box
Frame articulation angle ±27°
Min. turning radius using articulation 5.9m
Biade
Maximum lift above ground 300mm
Maximum depth of cutting 350mm
Maximum blade position angle 45°
Blade cutting angle 28°—70°
Circle reversing rotation 120°
Moldboard width X height 3048×500mm





              All technical parameters are subject to change without prior notice because of technical improvements.
