HB48-B-C-D Concrete Pump

HB48 Truck-Mounted Concrete Pump



HB48-B-C-D concrete pump is the medium size of XCMG machine, and widely applied in high buildings and large foundation equipments of bridge, power plant, steel plant, water treatment plant. The machine features environmental care, safety, reliability and advanced.





Travel

Category

Item

Unit

Parameter

Parameter

Parameter

Chassis

Model



FM

Actros4141

FY1EWV

Manufacturer



VOLVO

Germany BENZ

Hino

Max. speed

km/h

94.8

85

85

Max. gradeability



35%

38%

39.90%

Min. turning diameter

m

24.605

25.9

24.4

Brake distance

m

≤10

≤10

≤10

Wheelbase

mm

1995+4405+1370

1700+4600+1350

1850+4605+1310

Tread (front/rear)

mm

2028/1837

2034/1804

2050/1855

Approach angle/departure angle

17/10

22/10

18.2/10

Min. clearance

mm

270

300

240

Tyre specification



315/80R22.5

315/80R22.5

315/80R22.5

Engine

Model



D13

OM501LA.Ⅲ/17

E13CTL

Output power

kw/(r/min)

294/1400~1800

300/1800

331/1800

Max. torque

N.m/(r/min)

2200/1050~1400

2000/1080

1912/1100

Displacement

l

12.8

11.946

12.913

Emission Standard



Nation III GBⅢ

Nation III GBⅢ

Nation III GBⅢ

Others

Dimension (length x width x height)

mm

12632×2500×3995

12590×2500×3995

12515×2500×3995

Total vehicle weight

kg

41000

41000

40000

Fuel tank capacity

l

410

400

400

Fuel consumption per 100km

l/100km

40

40

40

Pumping operation

Pumping system

Theoretical output(high pressure/low pressure)

m3/h

90/138

90/150



Concrete pumping pressure(high pressure/low pressure)

Mpa

13/8.7

13/8



Theoretical pumping times(high pressure/low pressure)

次/min

18/27

13/21



Max. diameter of pumping concrete aggregate

mm

40





Feeding height

mm

1540





Placing boom

Pumping slump range

cm

12-23





Reach height

m

48.1





Reach depth

m

34





Slewing radius

m

42.75





Slewing angle

370





1st boom stretch angle

90





2nd boom stretch angle

180





3rd boom stretch angle

180





4th boom stretch angle

250





5th boom stretch angle

250





Outrigger span Overall outrigger span

mm

10500





Front outrigger transverse span

mm

10450





Rear outrigger transverse span

mm

10300





Others

Dosing type



S valve

S-valve



Lubricating method



Automatic lubrication

Automatic



Controlling method



Manual/remote control

Manual/Remote control

Water tank capacity

l

600





Max. pressure of water pump

Mpa

2
