WZ30-25C Backhoe Loader

WZ30-25C Backhoe Loader



Description of Backhoe Loader:
Backhoe loader, commonly shortened to backhoe, is a type of construction machinery/construction equipment. The backhoe loader commonly composes a tractor, fitted with a shovel/bucket on the front and a small backhoe on the back.
Features of Backhoe Loader WZ30-25C:
1. Equipped with WD DETUZ engine
2. 4 forward & 4 reverse synchromesh mechanical shift transmission
3. Combined seal cylinder obtains high seal performance and more reliability
4. Improved loader and backhoe performance
5. CARRARO wet type rear axle with multi-disc brake& CARRARO front axle
6. New-type cab with more space, increases comfort and visibility
7. With 2 wheel driving or 4 wheel driving for option
Applications of Backhoe Loader WZ30-25C:
The backhoe loaders’ versatility and compact size makes them one of the most popular construction machinery/construction equipment. These backhoe loaders are widely used for larger projects such as building a house, fixing city roads, mining, etc.
Working principle of Backhoe Loader WZ30-25C:
Because the design of backhoe loaders is top-heavy and the swinging weight of the backhoe could cause the vehicle to tip, backhoe loaders use hydraulic outriggers when digging and lower the loader bucket for additional stability.
Specifications of Backhoe Loader WZ30-25C:

Overall Dimension

1

Length(with bucket on ground)

7077(mm)

2

Width

2350(mm)

3

Load Bucket width

2328(mm)

4

Height(To the top of the cab)

2735 (mm)

5

Height(To the top of the digging pole)

3424 (mm)

6

Wheelbase

2155.5(mm)

7

Back wheel Tread

1557(mm)

8

Fore wheel Tread

1714(mm)

9

Min. ground clearance

355(mm) for 2WD 275(mm) for 4WD

Main Loading Technical Specification

1

Rated load

1700(Kg)

2

Operating weight

7400KG

3

Max lifting capability

>2500KG

4

Rated load bucket capacity

1.0(m3)

5

Max. load breakout force

>40kN

6

Max. dump clearance

2611(mm)

7

Max. Dump reach

726(mm)

8

Dump angle at any position

≥43.50

9

Min. turning radius

(1) Outside of bucket

5280(mm) for 2WD 5670(mm) for 4WD

(2) Center of front wheel

3795 (mm) for 2WD 4300(mm) for 4WD

10

Lifting time of loading bucket

≤5.1(sec.)

11

Lowering time of loading bucket

≤4.9(sec.)

12

Dumping time

≤0.9(sec.)

13

Traveling speed(Km/h)4 forward and 4 reverse

(1) gear forward

5.8

(2) gear forward

10.5

(3) gear forward

20.1

(4) gear forward

40.2

(1) gear reverse

7.0

(2) gear reverse

12.6

(3) gear reverse

24.3

(4) gear reverse

48.6

Main Digging Technical Specification

1

Rated digging bucket capacity

0.3(m3)

2

Max. digging depth

4338(mm)

3

Max. digging force

>50+10kN

4

Max. digging radius

5481(mm)

5

Max. dumping height

3737(mm)

Diesel engine

1

Model

WD DEUTZ T226B

2

Type

Direct injection. Turbocharged. Water cooling

3

Rated output

70 (kW)

4

Total exhaust of cylinder

3.92(L)

5

Inter-bore of cylinder/stroke

102/120(mm)

6

Voltage of starting motor

12(V)

7

Rated speed

2200(r/min)

8

Max. Torque

360(N.M)

9

Starting type

Electric

10

Min. specific fuel consumption

216(g/Kw.h)

Transmission System

1. Torque Converter

1

Model

CARRARO

2

Cooling type

Pressure oil circulating

2. Transmission case

1

Model

CARRARO

2

Type

Synchromesh mechanical shift

3

Gear shift posit

4 Forward and 4 reverse gears

3. Axle and Tire

1

Model

CARRARO

2

Type of main reducer

spiral bevel gear, single stage

3

Type of final reducer

Single stage planetary

4

Max. steering angle

550

5

Tire type

4WD fore tire12-16.5NHS-10PR

2WD fore tire11L-16F3-12PR

Rear tire 19.5L-24R4-12PR

Working Device Hydraulic System

1

Model of oil pump

JHP2050AXCC

2

System pressure

215(kgf/cm2)

3

Model of load valve

ZL20DC-02

4

Model of excavate valve

ZL30DC-07

Steering System

1

Type

Fore wheel Steering

2

Model of steering pump

JHP2050AXCC

3

Model of Redirector

BZZ5-E160B+ FKB-3022

4

Model of priority valve

YXL-F160L-N7

5

System pressure

140(kgf/cm2)

Oil Capacity

1

Fuel(diesel)

151(L)

2

Engine lubricating oil

11(L)

3

Oil for converter and gear box

For 2WD

18.5(L)

For 4WD

21(L)

4

Oil for hydraulic system

110(L)

5

Oil for driving axles(F/R)

7.617(L)
