SQ14SK4Q Truck-Mounted Crane

SQ14SK4Q Truck-Mounted Crane



Parameter



Max Lifting Capacity

14000

kg

Max Lifting Moment

35

T.M

Recommend Power

32

kw

Max Oil Flow of Hydraulic System

63

L/min

Max Pressure of Hydraulic System

26

MPa

Oil Tank Capacity

160

L

Rotation Angle

All Rotation

Crane Weight

4800

kg

Installation Space

1300

mm

Choice of Chassis

BJ1317VNPJJ-S5北汽福田;NXG1310D3ZEX徐工;

SQ14SK4Q Lifting capability diagram



Working radius(m)

2.5

5

8

11

13.2

15.8

Lifting capacity(kg)

14000

6000

3500

2300

1800

1200
