SQ6.3ZK2Q/K3Q Truck-Mounted Crane

SQ6.3ZK2Q/K3Q Truck-Mounted Crane



Parameter

Max Lifting Moment

13.23

13.23

t.m

Max Lifting Capacity

6300

6300

kg

Recommend Power Needed At Recommend Oil Flow

18

18

kw

Max Oil Flow of Hydraulic System

25

25

L/min

Rated Pressure Of Hydraulic System

28

28

MPa

Oil Tank Capacity

90

90

L

Rotation Angle

(360°)All Rotation

(360°)All Rotation

°

Crane Weight

2115

2226

kg

Installation Space

1050

1050

mm

Choice of Chassis

CA1163P7K2L3E 解放;CA1176PK2L9T3A95 柳特CA1170PK2L7T3EA80青岛解放; CA1140PK2L3EA80 青岛解放 ; DFL1140B东风;EQ1126KJ1东风;HFC1132KR1K3江淮;HFC1202KR1K3江淮;EQ1141NBJ2东风;EQ5161GFJ7东风;BJ1317VNPJJ-S5北汽福田;EQ5201GFJ6东风;LZ1160LCMT东风柳汽;DFL1250A9东风;BJ5317ZNPJJ-S北汽福田;HN1310P29D6M3J 华凌;NXG1160D3ZAL1X徐工;

SQ6.3ZK2Q Lifting capability diagram



Working radius (m) 2.1 4.44 6.2 8.01
Lifting capacity (kg) 6300 2700 1700 1200

SQ6.3ZK3Q Lifting capability diagram



Working radius (m)

2.1

4.54

6.3

8.11

9.92

Lifting capacity (kg)

6300

2700

1700

1200

 850
