JP25 Water Tower Fire Truck

JP25 Water Tower Fire Truck



    JP25 Water Tower Fire Truck is a vehicle of hydraulic drive, 360º full swing with a 3-section folding boom. The superstructure is mounted on a “Dongfeng” EQ1141G7DJ2 Ⅱchassis. H-shaped outriggers and large box-typed sub-frame are available. The fire fighting water pump is installed on the front of the sub-frame. The turntable locates at the rear of the sub-frame. Stainless steel water pipeline is fixed along the right side of the folding boom. The hydraulic-driven double-purpose foam-water monitor is fixed at the tip of the 3rd boom section. The electro-hydraulic proportional control and cable remote control are applied in the vehicle. Safety devices are well equipped. Advanced performance, smooth movements, fine inching control, safe operations are available.





Parameter



1Main Technical Data in Travel Configuration

Category

Item

Unit

Parameter

Dimension

Overall length

mm

9700

Overall height

mm

3800

Overall width

mm

2500

Wheel space

mm

5000

Track

Front axle

mm

1940

Rear axle

mm

1860

Weight

Gross weight

kg

13500

Axle load

Front axle

kg

4750

Mid/Rear axle

kg

8750

Travel parameter

Chassis

Dongfeng EQ1141G7DJ2

Engine model

Cummins 6BTA5.9

Power

kW/(r/min)

132/2500

Torque

N·m/(r/min)

610/1500

Max. travel speed

km/h

≥90

Min. turning diameter

m

≤18

Approach angle

°

≥25

Departure angle

°

≥10

Braking distance (at speed 30km/h )

m

≤10

Min. ground clearance

mm

248

Max. grade-ability

%

≥28


2Main Technical Data for Operation

Category

Item

Unit

Parameter

Main performance

Rated working height

m

25

Max. working radius

m

15



Boom elevating range

Angle of 1st boom section tohorizontal

°

0~80

Angle of 2nd boom section to 1st boom section

°

0~140

Angle of 3rd boom section to2nd boom section

°

0~210

Outrigger span

(longitudinal×lateral)

m

5.2×4.5
