CDZ32 Aerial Platform Fire Truck

CDZ32 Aerial Platform Fire Truck




    CDZ32 is Fire Truck with telescopic boom plus folding jib and additional telescopic rescue ladder. The working cage is articulated at the end of the jib with rated load 400kg. The water pipeline in fire fighting system installed along the right side of the telescopic boom can telescope with the telescopic boom. Operation of the vehicle can be performed respectively on the turntable and on the working cage. Double cylinders for front support elevating, H-shaped outriggers and 360°full swing are available. Lower structure consists of general chassis and sub frame. Safety devices are well equipped.



Parameter



1、Main Technical Data in Travel Configuration

Category

Item

Unit

Parameter

Dimension

Overall length

mm

12000

Overall height

mm

3980

Overall width

mm

2500

Wheel space

1st, 2nd axle

mm

4450

2nd, 3rd axle

mm

1450

Weight

Gross weight

kg

25230

Axle load

Front axle

kg

6480

Mid/Rear axle

kg

18750

Travel parameter

Chassis

Benz 2628

Engine model

MB OM906LA

Power

kW/(r/min)

205/2300

Torque

N·m/(r/min)

1100/1250~1500

Max. travel speed

km/h

≥85

Min. turning diameter

m

≤24

Approach angle

°

≥26

Departure angle

°

≥10

制动距离(车速为30km/h) Braking distance (at speed 30km/h )

m

≤9.5

最小离地间隙

Min. ground clearance

mm

339

最大爬坡度Max. grade ability

%

≥25


2、Main Technical Data for Operation

Category

Item

Unit

Parameter

Main performance

Rated working height

m

32

Rated load on the platform

kg

400

Max. rated working radius

m

17

Telescopic boom length

m

11.2~26.2

Folding jib length

m

5

Outrigger span

(longitudinal×lateral)

m

5.5×5.5

Elevating range

°

-3~80
